KGBAS12-PP-AS
Linear ball bearing and housing unit
Linear ball bearing and housing unit; sealed, greased, with relubrication facility; corrosion-resistant design possible
Main Dimensions & Performance Data
| FW | 12 mm | Diameter of ball complement |
| H | 34 mm | Height |
| L | 32 mm | Length |
| Tol L | h12 | Tolerance |
| B | 42 mm | Width |
| C | 540 N | Load capacity dyn. C 1 |
| C0 | 385 N | Load capacity stat. C0 1 |
| ≈m | 80 g | Ağırlık |
Mounting dimensions
| JB | 32 mm | |
| Tol JB | +0,15 | Upper tolerance |
| Tol JB | -0,15 | Lower tolerance |
| A5 | 21 mm | |
| Tol A5 | +0,01 | Upper tolerance |
| Tol A5 | -0,01 | Lower tolerance |
| L4 | 32 mm | |
| L5 | 20 mm | |
| JL | 23 mm | |
| Tol JL | +0,15 | Upper tolerance |
| Tol JL | -0,15 | Lower tolerance |
| H2 | 18 mm | Center Height |
| Tol H2 | +0,01 | Upper tolerance |
| Tol H2 | -0,01 | Lower tolerance |
| A3 | 15 mm | |
| H6 | 4,8 mm | |
| Tol H6 | -0,5 | Tolerance |
| N1 | 4,7 mm | |
| N3 | 8 mm | |
| K5 | M4 | |
| K8 | NIPA1 | Lubrication nipple |
| W | 7 mm | Width across flats |
5 | Ball rows |
Dipnotlar
1
İndirmeler:
Mevcut ürün modeliniz
| Size code | 12 | |
| Seal | PP | |
| Relubrication feature | AS |
