7313-B-XL-TVP
Angular contact ball bearing
Angular contact ball bearing 73..-B-XL-TVP, single row, X-life, plastic cage
Yerine geçer
7313-B-TVP, 7313B.TVP
Tercih edilen ürün
Main Dimensions & Performance Data
| d | 65 mm | Bore diameter |
| D | 140 mm | Outside diameter |
| B | 33 mm | Width |
| Cr | 110.000 N | Basic dynamic load rating, radial |
| C0r | 82.000 N | Basic static load rating, radial |
| Cur | 5.600 N | Fatigue load limit, radial |
| nG | 6.500 1/min | Limiting speed |
| nϑr | 5.000 1/min | Reference speed |
| ≈m | 2,115 kg | Ağırlık |
Mounting dimensions
| da min | 77 mm | Minimum diameter of shaft shoulder |
| Da max | 128 mm | Maximum diameter of housing shoulder |
| Db max | 133 mm | Maximum diameter of housing shoulder |
| ra max | 2,1 mm | Maximum fillet radius of shaft |
| ra1 max | 1 mm | Maximum fillet radius of housing |
Dimensions
| rmin | 2,1 mm | Minimum chamfer dimension |
| r1 min | 1,1 mm | Minimum chamfer dimension |
| D1 | 111,52 mm | Shoulder diameter on outer ring wide side face |
| d1 | 95,3 mm | Shoulder diameter on inner ring wide side face |
| a | 59,5 mm | Distance between the apexes of the pressure cones |
| α | 40 ° | Contact angle |
Temperature range
| Tmin | -30 °C | Operating temperature min. |
| Tmax | 120 °C | Operating temperature max. |
